discontinued
There is a newer model of this item:
Need help finding a replacement?
-
Call us at
888-714-4938
About the Frigidaire FFEC3005LB
- 4 Coil Heating Elements
- Ready-Select Controls
Brand:
Cooktop Type:
Cooktop
Finish:
Black
Fuel Type:
Electric
Style:
Coil
Width:
30"
Height:
3"
Depth:
21 1/2"
Cutout Width:
26 3/4"
Cutout Height:
5"
Cutout Depth:
20"
Volts:
240/208 Volts
Amps:
20
Through meaningful innovations, Frigidaire has humanized their technology to create appliance designs that are uncluttered, controls that are intuitive, and features that are as useful as they are smart. This 30" electric cooktop is approved for installation above any Frigidaire Single Electric Wall Oven. Get yours today at Designer Appliances.
Key Features
30" Electric Cooktop
Ready-Select Controls
- Easily select options with the touch of a button
Approved Over Frigidaire Electric Wall Ovens
- Cooktops are approved for installation above any Frigidaire single electric wall ovens
FFEC3005LB Owner's Guide
Key Features
SpillSafe Drip Bowls
Cooktop features chrome drip bowls that make cleaning up spills quick and easy.
Ready-Select Controls
Select options or control cooking temperature with our easy to use controls.
Color-Coordinated Control Knobs
White, Black and Bisque cooktops come with matching knobs - while Stainless Steel models feature our neutral black knobs.
Specifications
Product Information
Warranty Terms
1 year ?Frigidaire Appliances are backed with a one year warranty. For additional information visit https://www.frigidaire.com/en/warranty/warranty-information
UPC
057112990132
Brand
Frigidaire
Model
FFEC3005LB
Cut-Out Dimensions
Connected Load (kW Rating) @ 240/208 Volts
6.7/5.0
Amps (240/208 Volts)
22.3/19.2
Cut-out Depth
19 1/8" - 20"
Cut-out Height
5"
Cut-out Width
26 3/4" - 28 1/4"
Voltage Rating
240/208V
Shipping Weight (approx.)
30 lbs
Product Weight
25 lbs
Frequency
60 Hz
Features
Size
30"
Product Type
Electric
Power Type
Electric
Power Supply Location
Rear Right
Model
FFEC3005LB
Controls
Express-Select
Control Location
Right Side
Color
Black
Approved for Single Oven Combo Installation
Yes
Cooktop Configuration
Surface Type
stainless
Rear Right Element
6"- 1,250W
Rear Left Element
8"- 2,100 Watts
Front Right Element
8"- 2,100 Watts
Front Left Element
6"- 1,250 Watts
Technical Details
Voltage
240/208 Volts
Star-K Certified
No
Amps
20
ADA Compliant
No
Modules Required
No
LP Conversion
No
Ignition Type
Electronic
Appearance
Type
Drop-In
Trim Color
Black
Surface Color
Black
Style
Coil
Cooktop
Cooktop
Color
Black
Number of Burners
4
Fuel Type
Electric
Exterior Dimensions
Width
30"
Height
3"
Exterior Depth (to Front Corner)
21-1/2"
Depth
21 1/2"
Burner Output
Set 2 QTY
2
Burner 2 Output
1250
Burner 1 Output
2100
Set 2 Output
1250
Set 1 QTY
2
Set 1 Output
2100
Grill
No
Griddle
No
Function
Control Type
Knobs
Burners / Elements
4
Burners
4
Sabbath Mode
No
Induction
No
Hot Surface Indicator Light
No
Downdraft Venting
No
Dimensions
Actual Width
30 Inch
Actual Height
3 Inch
Cutout Depth
20 Inch
Cutout Height
5"
Cutout Width
26 3/4 Inch
Actual Depth
21 1/2 Inch
General
Manufacturer
Frigidaire
