About the Frigidaire FFEF3000MW
- 4 Coil Elements
- 4.2 cu. ft. Manual Clean Oven
- Chrome Drip Bowls
- 2 Oven Racks
Brand:
Style:
Freestanding
Width:
29 7/8"
Height:
47 1/2"
Depth:
28 1/2"
Capacity:
4.2 Cu. Ft.
Burners:
4
Convection:
No
Self Clean:
No
Griddle:
No
Grill:
No
Fuel Type:
Electric
Volts:
240/208 Volts
Amps:
40
Frigidaire, one of the leaders in home appliances; offers superior products and service to rival many other companies. Through meaningful innovations, they've humanized their technology to create appliance design that's uncluttered, controls that are intuitive, and features that are as sensitive as they are smart.
Key Features
Manual Clean Oven
Chrome Drip Bowls
Towel-Bar Handle
2 Oven Racks
ADA Compliant
Available At Designer Appliances
www.designerappliances.com
Manuals & Downloads
FFEF3000MW Installation Instructions
FFEF3000MW Owner's Guide
FFEF3000MW Wiring Diagram
Specifications
Oven Features
Broiler Pan Included
No
Primary Oven Capacity
4.2 Cu. Ft.
Oven Control Type
Knobs
Digital Temperature Display
No
Timer
No
Convection
No
Self-Cleaning
No
Delay Bake
No
Proofing
No
Sabbath Mode
No
Broiler Element Location
Top
Temperature Probe
No
Interior Oven Light
No
Racks
2
Removable Door
Yes
Proof Mode
No
Oven Features
Even Baking System
No
Rack Configuration
2 Standard
Hidden Bake Element
No
Oven Light
No
Capacity
4.2 Cu. Ft.
Broiling System
Standard
Bake Element
2,600 Watts
Broil Element
3,000 Watts
Cooktop Features
Drip Bowls
Chrome
Coil Cooktop
Yes
Hot Surface Indicator Light
No
Center Element
N/A
Left Rear Element
6" - 1,250 Watts
Left Front Element
8" - 2,100 Watts
Right Rear Element
6" - 1,250 Watts
Right Front Element
6" - 1,250 Watts
Features
A.D.A. Compliant
Yes
Drawer Functionality
N/A
Oven Cleaning System
Manual Clean
Convection System
No
Exterior Finish (Side Panels)
White
Handle Design
White
Exterior Door Finish
White
Window
No
Surface Type
White Porcelain
Timing System
No
Oven Control
Mechanical
Appearance
Fuel Type
Electric
Style
Freestanding
Color
White
Cooktop
Coil
Stainless Steel Handle
No
Viewing Window
No
Drawer
None
Clock
No
Dimensions
Width
29 7/8 Inch
Depth
28 1/2 Inch
Height
47 1/2 Inch
Interior Width
23 Inch
Interior Depth
19 3/16 Inch
Interior Height
15 7/8 Inch
Burner Output
Set 1 QTY
1
Set 1 Output
2100
Set 2 QTY
3
Set 2 Output
1250
Burner 1 Output
2100
Burner 2 Output
1250
Cooktop Features
Burners / Elements
4
Cooktop Control Type
Knobs
Downdraft Ventilation
No
Modules Required
No
Hot Surface Indicator Light
No
Induction
No
Grill
No
Griddle
No
Technical Details
Star-K Certified
No
ADA Compliant
Yes
Oven Wattage
3,000
Amps
40
Voltage
240/208 Volts
Oven Controls
Bake
Yes
Broil
Yes
Add-a-Minute
No
Delay Bake
No
Self-Clean
No
Quick Clean Option
No
Delay Clean
No
Kitchen Timer
No
Timed Cook Option
No
Auto Oven Shut-Off
No
Specifications
Power Supply Connection Location
Middle Bottom Rear
Voltage Rating
240/208V / 60Hz
Connected Load (kW Rating) @ 240/208 Volts
8.8/7.9 kW
Minimum Circuit Required
40 Amps
Shipping Weight (Approx.)
135 Lbs.
Dimensions
Oven Interior Width
23"
Oven Interior Depth
19 3/16"
Oven Interior Height
15 7/8"
Overall Width
29 7/8"
Overall Depth
28 1/2"
Overall Height
47 1/2" Max.
Cutout Width
30" Min.
Cutout Depth
24" Min.
Cutout Height
36"
Overall Depth with Door Open 90°
48 3/8"
Product Information
Brand
Frigidaire
Model
FFEF3000MW
UPC
012505506710
Warranty Terms
1 year ?Frigidaire Appliances are backed with a one year warranty. For additional information visit https://www.frigidaire.com/en/warranty/warranty-information
Capacity
Number of Burners
4
General
Manufacturer
Frigidaire
