discontinued
There is a newer model of this item:
Need help finding a replacement?
-
Call us at
888-714-4938
About the KitchenAid KFGS306VSS
- 30" Gas Cooktop with 5 Sealed Burners
- Electronic Ignition and Infinite Position Control Knobs
Brand:
Cooktop Type:
Cooktop
Finish:
Stainless Steel
Fuel Type:
Gas
Style:
Sealed Burner
Width:
30"
Height:
3 5/8"
Depth:
21"
Cutout Width:
28 7/8"
Cutout Depth:
19 1/16"
Volts:
120 Volts
Amps:
15
The first 30-inch 5-burner cooktop among leading manufacturers of gas cooktops offers distinct style. Three cast-iron grates span the entire cooktop surface, allowing you to slide cookware. And low profile grates create a desirable look that integrates with the countertop.
Key Features
- First 30-inch 5-burner cooktop among leading manufactureres of gas cooktops
- 15K BTU professional dual tier burner provides versatility for varied cooking styles - from simmering to searing
- 6K BTU simmer burner cooks food gently at low temperatures
- Low profile full-width cast-iron grates allow easy movement of cookware around the entire cooktop surface
- Sealed burners prevent spills and drips from entering the burner box
- Automatic reignition immediately reignites burner if the flame is blown out
KFGS306VSS Owners Manual
Specifications
Technical Details
Voltage
120 Volts
Star-K Certified
No
Amps
15
ADA Compliant
No
Ignition Type
Electronic
Modules Required
No
LP Conversion
Yes
Cooktop Features
Left Rear Power
6,000 BTU
Left Front Type
Burner
Left Front Power
10,000 BTU
Center Rear Type
Professional Dual Tier
Center Rear Power
17,000 BTU
Left Rear Type
Simmer
Right Front Power
10,000 BTU
Right Front Type
Burner
Right Rear Type
Burner
Right Rear Power
7,000 BTU
Dimensions and Weight
Width
30"
Height
3 5/8"
Gross Weight
60 Lbs.
Depth
21"
Cutout Width
28 7/8"
Cutout Depth
19 1/16"
Style and Extras
Power Boost
No
Hot Surface Indicator Light
No
Heating Element On Indicator Light
No
Downdraft Vent
No
Digital Display
No
Control Type
Knobs
Appearance
Trim Color
Stainless Steel
Surface Color
Stainless Steel
Style
Sealed Burner
Fuel Type
Gas
Cooktop
Cooktop
Continuous Grates
Yes
Color
Stainless Steel
Electrical Requirements
Volts
120
Amps
15
Configuration and Overview
Surface Material
Stainless Steel
Size
30"
Number of Burners
5
Installs Over Built-In Oven
Yes
Fuel Type
Gas
Cooktop Type
Standard
Burner or Element Style
Sealed Gas
Burner Output
Griddle
No
Grill
No
Set 5 QTY
1
Set 5 Output
6000
Set 4 QTY
1
Set 4 Output
6000
Set 3 QTY
1
Set 3 Output
7000
Set 2 QTY
2
Set 2 Output
10000
Set 1 QTY
1
Set 1 Output
17000
Function
Downdraft Venting
No
Control Type
Knobs
Burners
5
Hot Surface Indicator Light
No
Sabbath Mode
No
Induction
No
Dimensions
Cutout Width
28 7/8"
Cutout Depth
19 1/16"
Actual Width
30"
Actual Height
3 5/8"
Actual Depth
21"
General
Series
Architect Series II
Manufacturer
KitchenAid
