discontinued
There is a newer model of this item:
Need help finding a replacement?
-
Call us at
888-714-4938
Frequently Bought Together
4 Item(s)
-
-
-
KitchenAid KOSE500EBS 30" Single Wall Oven w/Even-Heat True Convection - Black Stainless Steel w/PrintShield Finish$3,199.00 Save $321.00$2,878.00 -
About the KitchenAid KGCC566RBL
- 36 Inch Gas Cooktop with 5 Sealed Burners
- Continuous Grates
- Gas-on-Glass Surface
- 17
- 000 BTU Professional Burner
- 16
- 000 BTU Simmer Burners
- Electronic Ignition: Pure Black
Brand:
Cooktop Type:
Cooktop
Finish:
Black
Fuel Type:
Gas
Style:
Sealed Burner
Width:
36 7/16"
Height:
2 7/8"
Depth:
20 5/16"
Cutout Width:
35 1/4"
Cutout Height:
3 3/8"
Cutout Depth:
19"
Volts:
120 Volts
Amps:
15
Key Features
Key Features
- Versatile burner options accommodate even the most creative cooking styles - from simmering to sauteing to searing.
- A 17,000 BTU professional burner delivers the maximum power you need for recipes that demand precision.
- Robust grates form an even, continous surface to make it easy to slide cookware back and forth.
- The infinite-heat control knobs activate a reliable electronic ignition for consistent performance, time after time.
KGCC566RBL Dimension Guide
Specifications
Burner Output
Simmer Burner
Yes
Burner 5 Output
6000
Burner 4 Output
6000
Burner 3 Output
9000
Burner 1 Output
17000
Burner 2 Output
12500
Set 1 Output
17000
Set 1 QTY
1
Set 2 Output
12500
Set 2 QTY
1
Set 3 Output
9000
Set 3 QTY
1
Set 4 Output
6000
Griddle
No
Grill
No
Set 4 QTY
2
Configuration and Overview
LP Convertible
Yes - Kit Included
Power Boost
No
Power Cord Included
Yes
Power Outage Compatible
Yes
Size
36"
UL
UL
Installs Over Built-In Oven
Yes
Hot Surface Indicator Light
No
Automatic Pan Detection
No
Cooktop Type
Standard
Downdraft Vent
No
Fuel Type
Gas
Heating Element On Indicator Light
No
Cooktop Details
Burners - 12,500 BTU
1
Burners - 17,000 BTU
1
Burners - 6,000 BTU Simmer
2
Burners - 9,000 BTU
1
Cooktop Element Style
Sealed Burner
Cooktop Surface Material
Ceramic Glass
Grate Details
Matte Finish, Continuous, Cast Iron Grates
Ignition Type
Direct Spark Ignition
Infinite Heat Controls
Yes
Left Front Element-Burner Type
Professional Burner
Left Rear Element-Burner Type
Simmer
Location of Controls
Front
Number of Cooking Element-Burners
5
Number of Grates
3
Push-to-Turn Controls
Yes
Product Dimensions & Weight
Approximate Weight
45 lb.
Depth
20 5/16"
Height
2 7/8"
Shipping Weight
62 lb.
Width
36 7/16"
Cutout Dimensions
Minimum Clearance to Side Wall - Both Sides
8 3/8"
Minimum Space to Backsplash or Vertical Wall
2 7/8"
Minimum to Countertop Front Edge
2 1/8"
Width
35 1/4"
Depth
19"
Appearance
Style
Sealed Burner
Surface Color
Black
Trim Color
Black
Type
Drop-In
Color
Black
Continuous Grates
Yes
Controls Location
Front
Cooktop
Cooktop
Number of Burners
5
Fingerprint Resistant
No
Fuel Subtype
Natural Gas
Fuel Type
Gas
Glass Surface
Yes
GTIN
UPC
05946995373
Technical Details
Voltage
120 Volts
ADA Compliant
No
Amps
15
Modules Required
No
Ignition Type
Electronic
LP Conversion
Yes
Electrical Requirements
Circuit Amps Required
15
120 Volts @ 60 Hz. Required
Yes
Smart
WiFi
No
Bluetooth
No
Function
Burners
5
Control Type
Knobs
Sabbath Mode
No
Downdraft Venting
No
Gas Cooktop Features
Cooktop Accessory
No Accessory
Dimensions
Actual Depth
20 5/16 Inch
Actual Height
2 7/8 Inch
Actual Width
36 7/16 Inch
Cutout Depth
19 Inch
Cutout Height
3 3/8"
Cutout Width
35 1/4 Inch
Product Information
Brand
KitchenAid
Model
KGCC566RBL
General
Series
Architect Series II
Manufacturer
KitchenAid
