discontinued
There is a newer model of this item:
Need help finding a replacement?
-
Call us at
888-714-4938
About the Miele KM360LP
- 24 Inch Gas Cooktop with 4 Sealed Burners
- Continuous Cast Iron Grates
- Ignition Safety Control
- Front Knob Controls
- QuickStart
- GasStop and Restart: Liquid Propane
Brand:
Cooktop Type:
Cooktop
Finish:
Stainless Steel
Fuel Type:
Gas
Style:
Sealed Burner
Width:
23 1/16"
Height:
2 3/16"
Depth:
20 1/4"
Cutout Width:
22"
Cutout Height:
1 1/2"
Cutout Depth:
19 5/16"
Volts:
120 Volts
Amps:
15
Cooking with gas is not always about the power; control is essential too. Operating at a low heat output is often as important as a high power setting, and all Miele units allow you to do that; this model will regulate as low as 620 BTU's.
Key Features
Burner Configuration:
- (1) 3,400 BTU Auxiliary / Simmer burner
- (2) 6,000 BTU Normal burners
- (1) 10,200 BTU High-speed burner
Standard features
- 4 cooking zones
- Center Control Configuration maximizes space between burners
- Completely sealed burners for easy cleaning and maintenance
- Continuous grate design permits pots to be moved effortlessly from burner to burner without lifting
- Unique ignition system optimizes cooktop safety and usability. If a flame goes out for any reason, re-ignition is initiated; should the flame not re-light, the system shuts down the flow of gas
- Available for LP or natural gas connection (must specify at the point of sale in order to obtain the correct unit configuration).
KM360LP Specifications
Specifications
Burner Output
Set 1 QTY
1
Set 2 Output
6000
Set 2 QTY
2
Set 3 Output
3400
Set 3 QTY
1
Simmer Burner
Yes
Burner 4 Output
3400
Burner 3 Output
6000
Burner 2 Output
6000
Burner 1 Output
10200
Power Burner
Yes
Grill
No
Griddle
No
Set 1 Output
10200
Dimensions & Weights
Minimum Recommended Distance to Ventilation Hood
30"
Shipping Depth
23 5/8"
Shipping Height
6 5/16"
Shipping Weight
32.5 Lbs
Shipping Width
26"
Width
23 1/16"
Minimum Back Spacing From Wall
2 3/4"
Height (To Electric Connection)
3"
Cutout Depth
19 5/16"
Cutout Width
22 1/16"
Depth
20 1/4"
Burner Output
Auxiliary/Simmer Burner
(1) 3,400 BTU
High-Speed Burner
(1) 10,200 BTU
Normal Burners
(2) 6,000 BTU
Total Maximum BTU Output
25,600 BTU
Electrical Specifications
Amps
15A
Frequency
60Hz
Power Cord
NEMA 5-15P, 4 ft (1.2 m)
Volts
120V
Gas
Gas Connection
1/2" NPT
Maximum Gas Supply Pressure
LP Gas - 14 � WC (34.9 mb), 1/2 psi (3.5 kPa)
Minimum Gas Supply Pressure
LP Gas - 10 � WC (25 mb)
Appearance
Style
Sealed Burner
Surface Color
Stainless Steel
Type
Drop-In
Color
Stainless Steel
Continuous Grates
Yes
Cooktop
Cooktop
Number of Burners
4
Fingerprint Resistant
No
Fuel Subtype
Liquid Propane
Fuel Type
Gas
Technical Details
Voltage
120 Volts
Amps
15
Ignition Type
Electronic
LP Conversion
No
Modules Required
No
Product Information
Warranty Terms
2 years ? Miele Appliances are backed by a two year warranty. For additional details, visit https://www.mieleusa.com/c/service-10.htm
Brand
Miele
Model
KM360LP
Appearance
Style
Sealed Burner
Number of Burners
4
Control Type
Knobs
Cooktop Type
Cooktop
Finish
Stainless Steel
Fuel Type
Liquid Propane
Accessory
Optional Accessory
GPCLKM0252L Ceramic and Stainless Cleaner 8.5 fl oz
Smart
WiFi
No
Bluetooth
No
Remote Control
No
GTIN
EAN
4002513771589
Function
Burners
4
Control Type
Knobs
Sabbath Mode
No
Downdraft Venting
No
Dimensions
Actual Depth
20 1/4 Inch
Actual Height
2 3/16 Inch
Actual Width
23 1/16 Inch
Cutout Depth
19 5/16 Inch
Cutout Height
1 1/2"
Cutout Width
22 Inch
Gas Cooktop Features
Cooktop Accessory
No Accessory
Dishwasher Safe Grates
Yes
French Top
No
General
Manufacturer
Miele
