About the Thermador CIT304GB
- 4 Heating Zones
- 3600W 11" Element
- PowerBoost
- Speed Heating
- Touch Control Panel
- Pan Recognition
Brand:
Cooktop Type:
Cooktop
Finish:
Stainless Steel
Fuel Type:
Induction
Style:
Smoothtop
Width:
31"
Height:
4 1/8"
Depth:
21 1/4"
Cutout Width:
28 3/4"
Cutout Height:
4 1/8"
Cutout Depth:
19 7/8"
Volts:
240/208 Volts
Amps:
40
Induction cooking is perhaps the most revolutionary advancement cooking technology has seen in the last 30 years. It offers both the responsiveness of gas and the convenience of an electric cooktop in a single unit. Like all Thermador products, the induction cooktops offer cutting-edge features and unrivalled performance. Plus, they design and manufacture their own induction components - using proprietary technology to ensure each cooktop meets their strict standards for quality and durability.
Once you experience the power and precision of Thermador induction cooking, you'll discover why no other induction cooktop comes close. Available at Designer Appliances.
Key Features
Performance
- Speed Heating - Induction cooktops heat 50% faster than traditional gas cooktops
- Large and powerful 11" element with 3600W
- PowerBoost allows the maximum power level to be exceeded in the shortest period of time
Design
- Touch control panel with blue light illumination offers 17 power settings
- Chiseled, angular design coordinates with the suite of Thermador Masterpiece Collection appliances
- Full stainless steel frame
- Trapezoid design control panel
Convenience
- Two Timers - Auto Shut Off Timer available for all elements enables user to set desired cooking times. Separate kitchen timer also available.
- Keep Warm function allows meals to remain ready to serve
Safety
- Pan Recognition - Element will not turn on if other small objects are placed on the cooking zone
- Anti-Overflow System - exclusive feature prevents spills by automatically shutting off and sounding alarm when liquids are detected on surface
- 2-step digital control panel indicates when elements are hot or very hot
- Child safety lock
Installation Above a Built-in Oven or Warming Drawer
- Thermador Induction Cooktops may be installed above a Thermador Single Built-in Oven.
- A minimum of 1" air gap must be maintained between the bottom of the cooktop and the top of the oven.
- Thermador Cooktops may also be installed above a Thermador Warming Drawer to create a convenient cooking center.
Important
- We strongly recommend the installation of a Thermador Ventilation System with this induction cooktop.
- Seal the surfaces of the cutout to make them heat resistant.
- This prevents the surfaces from expanding as a result of humidity.
- Solid surface counter-tops often require special installation.
- For example, heat reflective tape or rounded corners may be necessary.
Warning
- To reduce the risk of ignition of nearby combustible materials, install the counter-top with a minimum distance of 2" from both side walls and the back wall.
Heat Shield
- The heat shield will require an additional 1" clearance below the cooktop.
- For safety reasons, the heat shield must be properly installed.
- This prevents components from overheating as a result of the recirculation of hot air from the cooktop.
- The heat shield is the same width as the cooktop.
- For shipping, it is screwed to the burner box.
- Once installed, the heat shield will be able to rotate freely.
Our Expert Video Review
CIT304GB Design Guide
Specifications
Product Information
Warranty Terms
2 years ?Thermador appliances includes a 2-year limited warranty covering the entire unit, including parts and labor. For full warranty details, please visit https://www.thermador.com/us/support/warranties
UPC
825225865599
Brand
Thermador
Series
Masterpiece
Model
CIT304GB
Cooktop Specifications
Left Rear Element (Size/Watts/Watts with PowerBoost)
6" / 1,400 W / 1,800 W
Left Front Element (Size/Watts/Watts with PowerBoost)
9" / 2,200 W / 3,300 W
Right Front Element (Size/Watts/Watts with PowerBoost)
6" / 1,400 W / 1,800 W
Right Rear Element (Size/Watts/Watts with PowerBoost)
11" / 2,400 W / 3,600 W
Total Number of Cooktop Elements
4
Cooktop Warranty Information (Full Warranty and Limited Warranty from Date of Instal
Parts Only
2nd to 5th Year
Glass Ceramic Surface/Electric Elements and Switches
Limited Warranty
Full Warranty Parts and Labor
1 Year
Dimensions & Weights
Total Cutout Height (Including Air Clearance)
4 1/8"
Product Width
31"
Product Depth
21 1/4"
Minimum Distance from Rear Wall
2"
Minimum Distance from Counter Front
2 1/4"
Minimum Air Clearance
1"
Cutout Width
28 3/4" - 28 7/8"
Cutout Height
3 1/8"
Cutout Depth
19 7/8" - 20"
Approximate Shipping Weight
49 lbs.
Technical Details
Voltage
240/208 Volts
Amps
40
ADA Compliant
No
Modules Required
No
Appearance
Type
Drop-In
Trim Color
Stainless Steel
Surface Color
Black
Style
Smoothtop
Color
Stainless Steel
Cooktop
Cooktop
Number of Burners
4
Fuel Type
Induction
Accessories
Sensor Strips
N/A
9" Sensor Pot, 6.6 qt.
SENSORPOT9
7" Sensor Pot, 3.6 qt.
SENSORPOT7
6" Sensor Pot, 1.9 qt.
SENSORPOT6
6" Sensor Pot, 1.3 qt.
SENSORPOTH
16" Skillet for Use with 13" Element
N/A
Electrical Specifications
Required Circuit Breaker
40 Amp
Electrical Supply
240/208V AC, 60 Hz
Conduit
39" Flexible 3-Wire
Burner Output
Set 3 QTY
2
Set 3 Output
1800
Set 2 QTY
1
Burner 3 Output
1800
Burner 2 Output
3300
Burner 1 Output
3600
Set 2 Output
3300
Set 1 QTY
1
Set 1 Output
3600
Grill
No
Griddle
No
Function
Control Type
Touch Sensor
Burners / Elements
4
Burners
4
Sabbath Mode
No
Induction
Yes
Hot Surface Indicator Light
Yes
Downdraft Venting
No
Dimensions
Actual Width
31 Inch
Actual Height
4 1/8 Inch
Cutout Depth
19 7/8 Inch
Cutout Height
4 1/8"
Cutout Width
28 3/4 Inch
Actual Depth
21 1/4 Inch
General
Manufacturer
Thermador
