Thermador HMCN36FS Masterpiece Series 36" Chimney Wall Hood - Blower Options

discontinued
There is a newer model of this item:

Need help finding a replacement?

John Carey
About the Thermador HMCN36FS
  • Chimney Wall Hood, Well Lit with 4 Speed Touch Controls, 8" Duct
  • Flexibility in selecting blower that is suitable for your cooking style
  • Internal, External Blower options
  • Dishwasher safe stainless-frame mesh filters
  • Telescopic chimney - adjustable at installation
  • Vertical Ducting
Brand:
CFM:
1,300 CFM
Speeds:
4
Venting Type:
Ducted
Style:
Chimney Style
Width:
35 1/2"
Height:
31"
Depth:
21 1/2"
A Thermador kitchen is more luxurious, more efficient and more beautiful than any other kitchen. Because for seven decades, Thermador has been at the forefront of fusing the art and science of design and ingenuity. From introducing the first built-in oven almost 50 years ago to revolutionizing gas cooktops with the patented Star Burner; and from designing the first retractable downdraft ventilation system to advancing speed cooking technology; Thermador has helped transform the American kitchen.

As you explore new culinary possibilities in your state-of-the-art Thermador kitchen, powerful Thermador ventilation systems dutifully work to keep the air in your kitchen and home fresh and clean. These powerful systems tackle unwanted smoke, grease, heat and odors quietly and efficiently with ventilation power that ranges from 400 to 1400 CFM and come in a variety of styles and configurations that will complement any kitchen design.
Key Features
Performance
  • 3 fan speeds plus 10 minute high-power operation mode
  • Filters are highly efficient at capturing grease
  • Powerfully quiet ventilation systems
Design
  • Classic chiseled design matches Thermador's Masterpiece Series family of kitchen appliances
  • Brushed stainless steel finish
  • Welded, polished seams for a flawless design
  • Premium electronic touch controls
Convenience
  • Halogen lighting spotlights your best recipes
  • Dishwasher safe stainless-frame mesh filters
  • Dimmer lighting - for those hours after a late meal
  • Built-in Clean Filter Reminder light
  • Telescopic chimney - adjustable at installation
  • Delayed shutoff tackles lingering odors for up to 10 minutes
  • Blowers sold separately
  • Choose from Inline, Remote or Integrated Blowers
Installation Options
  • Thermador Chimney Wall Hoods may be installed above a Thermador non-professional gas, electric or induction cooktop to create a convenient cooking center.
  • Hood installation height above a cooktop or range can vary.
  • To obtain the necessary installation height above a Thermador non-professional gas, electric or induction cooktop, consult the appliance's installation manual.
  • Thermador Chimney Wall Hoods must be mounted on a wall.
  • These hoods are designed to be used for vertical discharge.
  • A blower must be purchased separately.
Our Expert Video Review
Specifications
Dimensions
Width
35 1/2 Inch
Depth
21 1/2 Inch
Height
31 Inch
Blower Specifications
Roof Plate Required - RFPLT1000
For use with VTR1030D & VTR1330E
Remote
VTR630D; VTR1030D; VTR1330E
Integral
VTN1080F
Inline
VTI610D; VTI1010D
CFM
600, 1000, 1300
Roof Plate Required - RFPLT600
For use with VTR630D
Total Amps @ 120 Volts, 60 Hz - VTI1010D
7.6
Total Amps @ 120 Volts, 60 Hz - VTI610D
5.8
Type - Remote
600/1000/1300 CFM
Type - Integral
1000 CFM
Type - Inline
600/1000 CFM
Total Amps @ 120 Volts, 60 Hz - VTR630D
6.7
Total Amps @ 120 Volts, 60 Hz - VTR1330E
9.2
Total Amps @ 120 Volts, 60 Hz - VTR1030D
7.8
Total Amps @ 120 Volts, 60 Hz - VTN1080F
5.0
Remote Blower Accessories
Roof Plate
RFPLT1000 (for use with VTR130D & VTR1330E)
Accessories
Chimney Extension
CHIMXHMC
Electrical Specifications
Required Circuit Breaker
15 or 20 Amp
Electrical Supply
120V AC, 60 Hz
Warranty
Limited Parts and Labor
1 Year
Hood Specifications
Transition with Backdraft Damper
Required (Purchase separately at most hardware stores)
Non-Ducted Capability
No
Halogen Lighting
3 Bulbs
Ducting Direction
Vertical
Duct Size at Discharge
8" Round
Dishwasher Safe Filters
3 Mesh with Stainless Frame
Ceiling Heights
8 ft. to 9 ft.
Blower
Sold Separately - See below for more info.
Available Hood Widths
36", 42"
Product Information
Warranty Terms
2 years ? Thermador appliances includes a 2-year limited warranty covering the entire unit, including parts and labor. For full warranty details, please visit https://www.thermador.com/us/
UPC
825225861621
Brand
Thermador
Model
HMCN36FS
Technical Details
Voltage
120 Volts
Amps
20
Energy Star Rated
No
Appearance
Venting Type
Ducted
Type
Hood
Style
Chimney Style
Color
Stainless Steel
Blower Type
Both
Mounting Type
Wall Mount
Features
Speeds
4
Dishwasher Safe Filters
Yes
Approved for Outdoor Use
No
Halogen Lighting
Yes
Number of Fan Speeds
4
Lighting Levels
1
GTIN
EAN
0825225861621
Specifications:
Series
Masterpiece
Capacity
CFM
1,300 CFM
Dimensions
Overall Height included Chimney
31" - 35"
Chimney Width
13 1/2"
Chimney Height
21 1/2"
Chimney Depth
11"
Canopy Width
35 1/2"
Canopy Height
9 1/2"
Canopy Depth
21 1/2"
General
Manufacturer
Thermador
