discontinued
There is a newer model of this item:
Need help finding a replacement?
-
Call us at
888-714-4938
About the Whirlpool GLS3064RS
- Description
- Specifications
- Features
- Info & Guides
- Reviews
Brand:
Cooktop Type:
Cooktop
Finish:
Stainless Steel
Fuel Type:
Gas
Style:
Sealed Burner
Width:
30"
Height:
2 27/32"
Depth:
20 1/8"
Cutout Width:
29 3/8"
Cutout Height:
2 27/32"
Cutout Depth:
19 1/2"
Volts:
120 Volts
Amps:
15
Key Features
- 30 in. Gas-on-Stainless Cooktop
- New Formed Styling, Graphics and Knobs
- Sealed Gas Burners
- Left Front: 15,000 BTU Power Burner
- Right Front: 9,000 BTU
- Left Rear: 9,000 BTU
- Right Rear: 12,000 BTU Power Burner
- Auto-Reignition
- Full-Width Cast Iron Burner Grates
- Recessed Grates
- Infinite-Heat Controls with Lift-Off Knobs
- LP Gas Conversion Kit Included
- 120V Electrical Requirement
GLS3064RS Owners Manual
Specifications
Product Information
Warranty Terms
1 year ? Whirlpool Appliances are backed by a one year warranty. For additional details, visit https://www.whirlpool.com/blog/kitchen/warranties.html
UPC
883049003566
Brand
Whirlpool
Model
GLS3064RS
Dimensions
Depth
20 1/8 in.
Height
2 27/32 in.
Width
30 in.
Performance
Minimum BTU
9,000
Maximum BTU
15,000
Gas Power
Yes
BTU Range
9,000 - 12,500
Burner Output
Set 3 QTY
2
Set 3 Output
9000
Set 2 QTY
1
Set 2 Output
12000
Set 1 QTY
1
Set 1 Output
15000
Burner 3 Output
9000
Burner 2 Output
12000
Burner 1 Output
15000
Grill
No
Griddle
No
General
Series
Gold
Manufacturer
Whirlpool
Controls
Dial Controls
Yes
Technical Details
Voltage
120 Volts
Modules Required
No
Amps
15
LP Conversion
Yes
Ignition Type
Electronic
Appearance
Type
Drop-In
Surface Color
Stainless Steel
Style
Sealed Burner
Number of Burners
4
Color
Stainless Steel
Continuous Grates
Yes
Fuel Type
Gas
Cooktop
Cooktop
Appearance
Trim Design
Trimless
Grate Finish
CAST IRON - MATTE FINISH
Construction
Sealed Gas Burners
Yes
Over Oven Installation
Yes
Number of Burners
4
Cooktop Surface
Porcelain-on-Steel
Burner Configuration
2 - 9,000 BTU 1 - 12,000 BTU 1 - 15,000 BTU
Function
Sabbath Mode
No
Burners / Elements
4
Burners
4
Downdraft Venting
No
Control Type
Knobs
Dimensions
Actual Width
30 Inch
Actual Height
2 27/32 Inch
Actual Depth
20 1/8 Inch
Cutout Width
29 3/8 Inch
Cutout Height
2 27/32"
Cutout Depth
19 1/2 Inch
GTIN
