About the Frigidaire FFGC3005LW
- 4 Open Burners
- Porcelain Surface
- Steel Grates
- Ready-Select Controls
Brand:
Cooktop Type:
Cooktop
Finish:
White
Fuel Type:
Gas
Style:
Open Burner
Width:
30"
Height:
3 1/4"
Depth:
21 1/2"
Cutout Width:
26 7/8"
Cutout Height:
5"
Cutout Depth:
19 3/8"
Volts:
120 Volts
Through meaningful innovations, Frigidaire has humanized their technology to create appliance designs that are uncluttered, controls that are intuitive, and features that are as useful as they are smart. This 30" gas cooktop features Ready-Select controls that allow you to easily select options with the touch of a button. Get yours today at Designer Appliances.
Key Features
Ready-Select Controls
- Select options or control cooking temperature with their easy-to-use controls.
Electronic Pilotless Ignition
- Saves energy and can be ignited manually when electricity is out.
Color-Coordinated Control Knobs
- White cooktops come with matching knobs.
Porcelain Cooktop Grates
- Grates are durable and easy to clean.
Easy-Clean, Lift-Up Cooktop
- Available at Designer Appliances.
- www.designerappliances.com
FFGC3005LW Owner's Guide
Specifications
Appearance
Number of Burners
4
Type
Drop-In
Trim Color
White
Surface Color
White
Color
White
Continuous Grates
No
Cooktop
Cooktop
Style
Open Burner
Fuel Type
Gas
Specifications
Amps @ 120 Volts
1.0 Amps
Connected Load (kW Rating) @ 120 Volts
.8 kW
Voltage Rating
120V / 60Hz / 15A
LP Conversion Kit
Included
Gas Supply Connection Location
Right Rear
Power Supply Connection Location
Right Rear
Minimum Circuit Required
15 Amps
Shipping Weight (Approx.)
35.0 Lbs.
Features
Bowl Type
N/A
Knob Type
Plastic
Knob Color
White
Control Location
Right Side
Left Rear Element
9,000 BTU
Left Front Element
9,000 BTU
Right Rear Element
9,000 BTU
Right Front Element
9,000 BTU
Grates
Steel Round with Black Gloss Finish
Surface Type
Color-Coordinated Porcelain
Controls
Ready-Select
Dimensions
Overall Width
30"
Cutout Height
5"
Cutout Depth
19" - 19 3/8"
Cutout Width
26 5/8" - 26 7/8"
Overall Height
2 3/4"
Overall Depth
21 1/2"
Burner Output
Burner 1 Output
9000
Set 1 QTY
4
Set 1 Output
9000
Grill
No
Griddle
No
Product Information
UPC
057112104072
Model
FFGC3005LW
Brand
Frigidaire
Function
Burners / Elements
4
Sabbath Mode
No
Hot Surface Indicator Light
No
Downdraft Venting
No
Control Type
Knobs
Burners
4
Dimensions
Cutout Height
5"
Cutout Depth
19 3/8 Inch
Cutout Width
26 7/8 Inch
Actual Height
3 1/4 Inch
Actual Depth
21 1/2 Inch
Actual Width
30 Inch
Technical Details
Voltage
120 Volts
LP Conversion
No
Modules Required
No
Ignition Type
Electronic
Star-K Certified
No
ADA Compliant
No
General
Manufacturer
Frigidaire
