discontinued
There is a newer model of this item:
Need help finding a replacement?
-
Call us at
888-714-4938
About the Frigidaire FFGC3015LB
- 4 Sealed Burners
- Cast Iron Grates
- Low Simmer Burner
- Ready-Select Controls
Brand:
Cooktop Type:
Cooktop
Finish:
Black
Fuel Type:
Gas
Style:
Sealed Burner
Width:
30"
Height:
5"
Depth:
21 1/2"
Cutout Width:
26 7/8"
Cutout Height:
5"
Cutout Depth:
19 3/8"
Volts:
120 Volts
Amps:
20
Through meaningful innovations, Frigidaire has humanized their technology to create appliance designs that are uncluttered, controls that are intuitive, and features that are as useful as they are smart. This 30" gas cooktop features Ready-Select controls that allow you to easily select options with the touch of a button. Get yours today at Designer Appliances.
Key Features
30" Gas Cooktop
Ready-Select Controls
- Easily select options with the touch of a button
Low Simmer Burner
- Perfect for delicate foods and sauces
FFGC3015LB Owner's Guide
Specifications
Product Information
Warranty Terms
1 year ?Frigidaire Appliances are backed with a one year warranty. For additional information visit https://www.frigidaire.com/en/warranty/warranty-information
UPC
057112104270
Brand
Frigidaire
Model
FFGC3015LB
Product Features
Shipping Weight (approx.)
50 lbs.
Product Weight
45 lbs.
Product Type
Gas cooktop
Power Type
Gas
Model
FFGC3015LB
Controls
Express-Select
Control Location
Right Side
Color
Black
Size
30"
Cooktop Configuration
Surface Type
Stainless
Rear Right Burner (BTU)
5,000
Rear Left Burner (BTU)
9,500
Grates
Cast Iron
Front Right Burner (BTU)
12,000
Front Left Burner (BTU)
9,500
Burner Output
Set 3 QTY
1
Set 3 Output
5000
Set 2 QTY
2
Set 2 Output
9500
Burner 3 Output
5000
Burner 2 Output
9500
Burner 1 Output
12000
Set 1 QTY
1
Set 1 Output
12000
Grill
No
Griddle
No
Cut-Out Dimensions
Cut-out Depth
19 - 19 3/8"
Cut-out Height
5"
Cut-out Width
26 5/8 - 26 7/8"
Technical Details
Voltage
120 Volts
Star-K Certified
No
Amps
20
ADA Compliant
No
Modules Required
No
LP Conversion
No
Ignition Type
Electronic
Appearance
Type
Drop-In
Trim Color
Black
Surface Color
Black
Style
Sealed Burner
Continuous Grates
Yes
Color
Black
Cooktop
Cooktop
Number of Burners
4
Fuel Type
Gas
Exterior Dimensions
Width
30"
Height
5"
Exterior Depth (to Front Corner)
21 1/2"
Depth
21 1/2"
Electrical
Voltage Rating
120V/60Hz
Power Supply Location
Rear Right
Amps (240/208 Volts)
1
Function
Burners / Elements
4
Burners
4
Control Type
Knobs
Sabbath Mode
No
Hot Surface Indicator Light
No
Downdraft Venting
No
Dimensions
Actual Width
30 Inch
Actual Height
5 Inch
Cutout Depth
19 3/8 Inch
Cutout Width
26 7/8 Inch
Cutout Height
5"
Actual Depth
21 1/2 Inch
General
Manufacturer
Frigidaire
