discontinued
There is a newer model of this item:
Need help finding a replacement?
-
Call us at
888-714-4938
About the Frigidaire FFEC3024LB
- 4 Cooking Zones
- Ready-Select Controls
- Ceramic Glass Cooktop
- SpillSaver Design
Brand:
Cooktop Type:
Cooktop
Finish:
Black
Fuel Type:
Electric
Style:
Smoothtop
Width:
30 3/4"
Height:
2 3/4"
Depth:
21 1/2"
Cutout Width:
29 5/8"
Cutout Height:
5"
Cutout Depth:
20 1/4"
Volts:
240/208 Volts
Amps:
40
Through meaningful innovations, Frigidaire has humanized their technology to create appliance designs that are uncluttered, controls that are intuitive, and features that are as useful as they are smart. This 30" electric cooktop is approved for installation above any Frigidaire Single Electric Wall Oven. Get yours today at Designer Appliances.
Key Features
30" Electric Cooktop
Ready-Select Controls
- Easily select options with the touch of a button.
Approved Over Frigidaire Electric Wall Ovens
- Cooktops are approved for installation above any of our single electric wall ovens.
Ceramic Glass Cooktop
- For a more beautiful cooktop that's easy to clean
Spill Saver Cooktop
- Cooktop contains your spillovers for easier clean up
FFEC3024LB Installation Instructions
Key Features
Ready-Select Controls
Select options or control cooking temperature with our easy to use controls.
Color-Coordinated Control Knobs
White, Black and Bisque cooktops come with matching knobs - while Stainless Steel models feature our neutral black knobs.
"On" Indicator
Alerts you when your cooktop is on.
Specifications
Product Information
Warranty Terms
1 year ?Frigidaire Appliances are backed with a one year warranty. For additional information visit https://www.frigidaire.com/en/warranty/warranty-information
UPC
057112990217
Brand
Frigidaire
Model
FFEC3024LB
Cut-Out Dimensions
Cut-out Height
5"
Cut-out Depth
20 1/4" - 20 1/2"
Cut-out Width
29 5/8" - 29 3/4"
Specifications:
Size
30"
Product Type
Electric cooktop
Power Type
Electric
Model
FFEC3024LB
Controls
Express-Select
Control Location
Right Side
Cooktop Configuration
Surface Type
Ceramic Glass
Rear Right Element
6"- 1,200 Watts
Hot-Surface Indicator Light
1
Front Right Element
9"- 2,500 Watts
Front Left Element
6"- 1,200 Watts
Burner Output
Set 2 QTY
2
Set 2 Output
1200
Set 1 QTY
2
Set 1 Output
2500
Burner 2 Output
1200
Burner 1 Output
2500
Grill
No
Griddle
No
Electrical
Frequency
60 Hz
Voltage Rating
240/208V
Technical Details
Voltage
240/208 Volts
Star-K Certified
No
Amps
40
ADA Compliant
No
Modules Required
No
LP Conversion
No
Ignition Type
Electronic
Appearance
Type
Drop-In
Trim Color
Black
Surface Color
Black
Style
Smoothtop
Color
Black
Cooktop
Cooktop
Number of Burners
4
Fuel Type
Electric
Exterior Dimensions
Width
30 3/4"
Shipping Weight (approx.)
45 lbs
Product Weight
40 lbs
Height
2 3/4"
Exterior Depth (to Front Corner)
21 1/2"
Depth
21 1/2"
Function
Control Type
Knobs
Burners / Elements
4
Burners
4
Sabbath Mode
No
Induction
No
Hot Surface Indicator Light
Yes
Downdraft Venting
No
Dimensions
Actual Width
30 3/4 Inch
Actual Height
2 3/4 Inch
Cutout Depth
20 1/4 Inch
Cutout Width
29 5/8 Inch
Cutout Height
5"
Actual Depth
21 1/2 Inch
General
Manufacturer
Frigidaire
