discontinued
There is a newer model of this item:
Need help finding a replacement?
-
Call us at
888-714-4938
About the Frigidaire FGEC3065KB
- 4 Elements Including 2 SpaceWise Expandable Elements
- Hot Surface Indicators
- Express-Select Controls
Brand:
Cooktop Type:
Cooktop
Finish:
Black
Fuel Type:
Electric
Style:
Smoothtop
Width:
30 3/4"
Height:
2 3/4"
Depth:
21 1/2"
Cutout Width:
29 5/8"
Cutout Height:
5"
Cutout Depth:
20 1/4"
Volts:
240/208 Volts
Amps:
40
Frigidaire, one of the leaders in home appliances; offers superior products and service to rival many other companies. Through meaningful innovations, they've humanized their technology to create appliance design that's uncluttered, controls that are intuitive, and features that are as sensitive as they are smart.
Key Features
More Easy-To-Use Features
- Smoothtop Ceramic Glass Cooking Surface
- 7" Element ( 1,500W )
- 6" Element ( 1,200W )
- Hot-Surface Indicators
- Available at Designer Appliances
- www.designerappliances.com
FGEC3065KB Installation Instructions
Specifications
GTIN
Dimensions and Weights
Overall Depth to Front Corner
21 1/2"
Overall Width
30 3/4"
Overall Height (Extreme Bottom to Topside of Cooktop)
2 3/4"
Overall Height (Extreme Bottom to Underside of Cooktop)
2 5/8"
Cut-Out Width
29 5/8" Min. - 29 3/4" Max.
Approx. Shipping Weight
60 Lbs.
Cut-Out Height
5" Min.
Cut-Out Depth
20 1/4" Min. - 201/2" Max.
Electrical Ratings
Voltage Rating
240/208V/60Hz
Minimum Circuit Requirement
40 Amps
Amps
35/30
Connected Load (Kw Rating) @ 240/208 Volts
8.4/6.3
Power Connection Location
Rear Right
Approved For Single Oven Combo Installation
Yes
Product Information
Series
Gallery
Warranty Terms
1 year ? Frigidaire Appliances are backed with a one year warranty. For additional information visit https://www.frigidaire.com/en/warranty/warranty-information
UPC
057112990033
Model
FGEC3065KB
Brand
Frigidaire
Technical Details
Voltage
240/208 Volts
Amps
40
Modules Required
No
ADA Compliant
No
Function
Sabbath Mode
No
Burners / Elements
4
Hot Surface Indicator Light
Yes
Induction
No
Downdraft Venting
No
Control Type
Knobs
Burners
4
Burner Output
Burner 4 Output
1200
Burner 3 Output
1500
Burner 2 Output
2700
Burner 1 Output
3000
Griddle
No
Grill
No
Set 4 Output
1200
Set 4 QTY
1
Set 3 Output
1500
Set 3 QTY
1
Set 2 Output
2700
Set 2 QTY
1
Set 1 Output
3000
Set 1 QTY
1
Appearance
Number of Burners
4
Type
Drop-In
Trim Color
Stainless Steel
Surface Color
Black
Color
Black
Cooktop
Cooktop
Style
Smoothtop
Fuel Type
Electric
Specifications
Power Type
Electric
Control Location
Right Side
Controls
Express-Select
Cooktop Configuration
Surface Type
Ceramic Glass
Left Front Element
9"/12" 1,700/2,700 Watts
Left Rear Element
6" 1,200 Watts
Right Front Element
6"/9" 1,600/3,000 Watts
Right Rear Element
7" - 1,500 Watts
Hot-Surface Indicator Light
Yes
Dimensions
Actual Width
30 3/4 Inch
Actual Depth
21 1/2 Inch
Actual Height
2 3/4 Inch
Cutout Height
5"
Cutout Depth
20 1/4 Inch
Cutout Width
29 5/8 Inch
General
Manufacturer
Frigidaire Gallery
