discontinued
There is a newer model of this item:
Need help finding a replacement?
-
Call us at
888-714-4938
About the Frigidaire FGEC3065KW
- 4 Elements Including 2 SpaceWise Expandable Elements
- Hot Surface Indicators
- Express-Select Controls
Brand:
Cooktop Type:
Cooktop
Finish:
White
Fuel Type:
Electric
Style:
Smoothtop
Width:
30 3/4"
Height:
2 3/4"
Depth:
21 1/2"
Cutout Width:
29 5/8"
Cutout Height:
5"
Cutout Depth:
20 1/4"
Volts:
240/208 Volts
Amps:
40
Frigidaire, one of the leaders in home appliances; offers superior products and service to rival many other companies. Through meaningful innovations, they've humanized their technology to create appliance design that's uncluttered, controls that are intuitive, and features that are as sensitive as they are smart.
Key Features
More Easy-To-Use Features
- Smoothtop Ceramic Glass Cooking Surface
- 7" Element ( 1,500W )
- 6" Element ( 1,200W )
- Hot-Surface Indicators
- Available at Designer Appliances
- www.designerappliances.com
FGEC3065KW Installation Instructions
Specifications
Product Information
Warranty Terms
1 year ? Frigidaire Appliances are backed with a one year warranty. For additional information visit https://www.frigidaire.com/en/warranty/warranty-information
UPC
057112990040
Brand
Frigidaire
Series
Gallery
Model
FGEC3065KW
Cooktop Configuration
Left Rear Element
6" 1,200 Watts
Left Front Element
9"/12" 1,700/2,700 Watts
Hot-Surface Indicator Light
Yes
Right Front Element
6"/9" 1,600/3,000 Watts
Right Rear Element
7" - 1,500 Watts
Surface Type
Ceramic Glass
Dimensions and Weights
Overall Width
30 3/4"
Overall Height (Extreme Bottom to Underside of Cooktop)
2 5/8"
Overall Height (Extreme Bottom to Topside of Cooktop)
2 3/4"
Overall Depth to Front Corner
21 1/2"
Cut-Out Width
29 5/8" Min. - 29 3/4" Max.
Cut-Out Height
5" Min.
Cut-Out Depth
20 1/4" Min. - 201/2" Max.
Approx. Shipping Weight
60 Lbs.
Burner Output
Set 4 QTY
1
Set 4 Output
1200
Set 3 QTY
1
Set 3 Output
1500
Set 2 QTY
1
Set 2 Output
2700
Set 1 QTY
1
Burner 4 Output
1200
Burner 3 Output
1500
Burner 2 Output
2700
Burner 1 Output
3000
Set 1 Output
3000
Grill
No
Griddle
No
Technical Details
Voltage
240/208 Volts
Amps
40
ADA Compliant
No
Modules Required
No
Appearance
Type
Drop-In
Trim Color
White
Surface Color
White
Style
Smoothtop
Color
White
Cooktop
Cooktop
Number of Burners
4
Fuel Type
Electric
Electrical Ratings
Voltage Rating
240/208V/60Hz
Power Connection Location
Rear Right
Minimum Circuit Requirement
40 Amps
Connected Load (Kw Rating) @ 240/208 Volts
8.4/6.3
Approved For Single Oven Combo Installation
Yes
Amps
35/30
Specifications
Power Type
Electric
Controls
Express-Select
Control Location
Right Side
Function
Burners / Elements
4
Burners
4
Control Type
Knobs
Sabbath Mode
No
Induction
No
Hot Surface Indicator Light
Yes
Downdraft Venting
No
Dimensions
Actual Width
30 3/4 Inch
Actual Height
2 3/4 Inch
Actual Depth
21 1/2 Inch
Cutout Width
29 5/8 Inch
Cutout Height
5"
Cutout Depth
20 1/4 Inch
GTIN
General
Manufacturer
Frigidaire Gallery
