About the GE JBS86EPES
- 30 Inch Electric Double Oven Range with 5 Radiant Elements
- 6.6 Cu. Ft. Total Capacity
- Ceramic Glass Smoothtop
- Steam Clean
- Power Boil Element
- Warming Zone
- Convection Oven
- 8-Pass Bake Element
- Fast Preheat
- Sabbath Mode: Slate
Brand:
Style:
Freestanding
Width:
29 7/8"
Height:
47"
Depth:
28 1/4"
Capacity:
4.4 Cu. Ft.
Convection:
Yes
Fuel Type:
Electric
Volts:
240/208 Volts
Amps:
40
GE Appliances, a Haier company, creates "good things, for life � through our passion for great appliances and the happiness they can bring to every household. With the Monogram®, Café⠢, GE Profile⠢, GE®, Haier®, and Hotpoint® brands, owners have more choices for making their kitchens and homes amazing each day. Our products include refrigerators, freezers, cooking products, dishwashers, washers, dryers, air conditioners and water filtration systems.
Key Features
30 Inch Electric Double Oven Range
- Lower Oven features Convection Bake/Roast for added versatility and is sure to accommodate all your cooking needs
5 Radiant Elements
- Variable size element rings and power burner capabilities
6.6 Cu. Ft. Oven Capacity
- 2.2 Cu. Ft. Upper Oven with 4.4 Cu. Ft. Lower Oven (with Convection)
Ceramic Glass Smoothtop
- One-Piece Upswept Cooktop, in Gray Patterned Ceramic Glass
Steam Clean
- A steam cleaning option cleans the oven cavity in a 30-minute cycle with less odor and heat
Additional Features
- Convection (Lower Oven)
- Warming Mode
- Proof Mode
- Sabbath Mode
Manuals & Downloads
JBS86EPES Installation Guide
JBS86EPES Specification Sheet
JBS86EPES User Manual
Key Features
Warming mode
A warming mode that lets you to serve dishes at the right time and temperature
Steam clean
A steam cleaning option cleans the oven cavity in a 30-minute cycle with less odor and heat
Fast preheat
The upper oven preheats quickly and evenly with a speedy preheat feature
Specifications
Range Features
Cooktop Surface
One-Piece Upswept. Gray Patterned Ceramic Glass
Oven Control Features
Audible Preheat Signal. Auto Oven Shut-Off with Override. C° or F° Programmable. Certified Sabbath Mode. Control Lock Capability. Delay Bake Option (Time Cook). Delay Clean Option. Electronic Clock & Kitchen Timer. Hi / Low Broil. Oven "ON" Light
Oven Cooking Modes
Warming
Oven Features
8-Pass Bake Element (Upper). 6-Pass Bake Element (Lower). 6-Pass Broil Element
Oven Rack Features
3 Heavy-Duty Oven Racks. 2 Upper / 7 Lower Rack Positions
Product Type
Free-Standing Double Oven
Oven Cleaning Type
Steam Clean (Both Ovens)
Melt Setting
Yes
Interior Oven Light
1 Incandescent (Upper). 1 Halogen (Lower). Preheat Notification
Cooktop Type
Radiant Smoothtop
Element - Center
6" 80W Warming Zone
Element - Left Front
9"/6" 3100W Power Boil
Element - Left Rear
6" 1200W
Element - Right Front
12"/9" 3000W
Element - Right Rear
6" 1200W
Fuel Type
Electric
Heating Element "ON" Indicator Light
1
Hot Surface Indicator Lights
1
Configuration
Double Oven Range
Control Location
Backsplash
Control Type
Digital Temperature Display. Electronic. Touchpads
Cooking Technology
Traditional Upper; Convection Lower
Cooktop Burner Type
Radiant. Smoothtop
Product Dimensions & Weights
Approximate Shipping Weight
226"
Cabinet Width
30"
Depth with Door Open
45"
Depth Without Handle
25 3/4"
Height to Cooking Surface (in.)
35 3/4" - 36 1/2"
Net Weight
204 lbs
Oven Interior Dimensions (lower)
24" x 17 1/2" x 18 1/4"
Oven Interior Dimensions (upper)
24" x 8-7/8" x 18-1/4"
Overall Depth
28 1/4"
Overall Height
47"
Overall Width
29 7/8"
Power Ratings
KW Rating at 240V
15.6
KW Rating at 208V
1.7
Broiler Wattage
2500W Upper / 3600W Lower
Bake Wattage
2500W Upper / 2650 Lower
Amp Rating at 208V
40
Amp Rating at 240V
40
Oven Features
Steam Clean
Yes
Temperature Probe
No
Timer
Yes
Convection
Yes
Delay Bake
Yes
Digital Temperature Display
Yes
Broiler Element Location
Top
Broiler Pan Included
No
Proof Mode
Yes
Sabbath Mode
Yes
Self-Cleaning Type
Steam
Glide Rack(s)
No
Interior Oven Light
Yes
Appearance
Style
Freestanding
Viewing Window
Yes
Clock
Yes
Color
Slate
Cooktop
Smoothtop
Cooktop Control Type
Knobs
Double Oven
Yes
Drawer
None
Fuel Type
Electric
Oven Control Type
Digital
GTIN
UPC
084691876366
Technical Details
Voltage
240/208 Volts
ADA Compliant
No
Amps
40
Oven Wattage
2,650
Product Information
Warranty Terms
1 year ? GE Appliances are backed by a one year warranty. For additional details, visit https://www.geappliances.com/ge/service-and-support/
Brand
GE
Model
JBS86EPES
Warranty
Labor Warranty
Limited 1-year entire appliance
Parts Warranty
Limited 1-year entire appliance
Dimensions
Width
29 7/8 Inch
Depth
28 1/4 Inch
Exterior Width
30 Inch
Height
47 Inch
Burner Output
Burner 5 Output
80W
Burner 4 Output
1200W
Burner 1 Output
3100W
Burner 2 Output
1200W
Burner 3 Output
3000W
Simmer Burner
Yes
Power Burner
Yes
Capacity
Secondary Oven Capacity
2.2 Cu. Ft.
Primary Oven Capacity
4.4 Cu. Ft.
Number of Burners
5
Electric Cooktop Features
Hot Surface Indicator Light
Yes
Induction
No
General
Manufacturer
GE
