KitchenAid KECC508RPW 30" Smoothtop Electric Cooktop with 4 Heating Elements, Premium Cooktop Surface & Touch-Activated Controls: Pure White

Brand: KitchenAid
Item: KECC508RPW

discontinued

Need help finding a replacement?

Call us at 888-714-4938

Save to Project

About the KitchenAid KECC508RPW

30" Smoothtop Electric Cooktop with 4 Heating Elements
Premium Cooktop Surface & Touch-Activated Controls: Pure White

Brand:

Cooktop Type:

Cooktop

Finish:

White

Fuel Type:

Electric

Style:

Smoothtop

Width:

30 5/16"

Height:

3 1/16"

Depth:

21 5/16"

Cutout Width:

29 1/2"

Cutout Height:

3 1/16"

Cutout Depth:

20 1/2"

Volts:

240/208 Volts

Amps:

The KECC508RP features KitchenAid's Custom Control temperature management system. The output of each element has been finely tuned to respond more like a gas burner. This gives you the precise control you need at high, medium and low temperatures. More consistency means chocolate melts evenly without constant attention, delicate sauces simmer without scorching, and you pan sear filets as if you were cooking over an open flame.

Key Features

Touch-Activated Controls - Designer Style and Precision Performance.
Custom Control Temperature Management System - Similar to Cooking on Gas.
Dual- and Triple-Ring Elements for Expanded Cookware Options.

Manuals & Downloads

KECC508RPW Owners Manual

KECC508RPW Dimension Guide

KECC508RPW Installation Instructions

KECC508RPW Warranty

Specifications

Technical Details

Voltage

240/208 Volts

Modules Required

Elements

Total Elements

Single Elements - 7" 1500W

Single Elements - 6 1/2" 1200W

Expanded Elements - Triple-Ring

10" Round (2500W/1600W/800W)

Expanded Elements - Dual-Ring

8" Round (2000W/1000W)

Performance

Custom Control Temperature Management System

Melt & Hold, Keep Warm and 3 Simmer Settings

Control Style

Touch-Activated

Burner Output

Set 4 QTY

Set 4 Output

Set 3 QTY

Set 3 Output

Set 2 QTY

Set 2 Output

Set 1 QTY

Set 1 Output

Grill

Griddle

Specifications

Approximate Weight

30 lbs.

Electrical Requirements

40A, 240V, 60HZ, A FOUR-WIRE OR THREE-WIRE, SINGLE PHASE ELECTRICAL SUPPLY REQUIRED. A TIME-DELAY FUSE OR CIRCUIT BREAKER AND SEPARATE CIRCUIT IS RECOMMENDED.

Appearance

Surface Color

White

Style

Smoothtop

Cooktop

Color

White

Fuel Type

Electric

Countertop Dimensions

Minimum to Countertop Front Edge
