discontinued
There is a newer model of this item:
Need help finding a replacement?
-
Call us at
888-714-4938
About the KitchenAid KGCK306VSS
- 30" Gas Cooktop with 4 Sealed Burners
- Electronic Ignition and Cast Iron Grates
Brand:
Cooktop Type:
Cooktop
Finish:
Stainless Steel
Fuel Type:
Gas
Style:
Sealed Burner
Width:
30"
Height:
3 3/8"
Depth:
21"
Cutout Width:
28 7/8"
Cutout Depth:
19 1/2"
Volts:
120 Volts
Amps:
15
This high end cooktop features four sealed burners, one 6,000 BTU simmer, one 9,000 BTU, one 12,500 BTU and one 17,000 BTU professional burner. This model is ideal for both the casual and the professional chef. In addition this cooktop is equipped with continuous grating, which allows you to move a pot from burner to burner without having to lift. The sleek stainless steel finish of this model is a welcome addition to any kitchen.
Key Features
- Versatile burner options accommodate a multitude of cooking styles - from simmering to sautéing to searing
- A 17K BTU professional burner promotes rapid boiling and accommodates high temperatures required by some recipes
- A 6K BTU simmer burner cooks food gently at low temperatures
- Full-width cast-iron grates allow easy movement of cookware around the entire cooktop surface
- Four sealed burners prevent spills and drips from entering the burner box
- Infinite-heat control knobs provide reliable and consistent performance from low to high temperature settings
KGCK306VSS Owners Manual
Specifications
Technical Details
Voltage
120 Volts
Star-K Certified
No
Amps
15
ADA Compliant
No
Modules Required
No
LP Conversion
Yes
Ignition Type
Electronic
Cooktop Features
Left Rear Type
Burner
Left Rear Power
10,000 BTU
Left Front Type
Burner
Left Front Power
9,100 BTU
Center Rear Type
Dual
Center Rear Power
17,000 BTU
Right Front Power
9,100 BTU
Right Front Type
Burner
Right Rear Power
5,000 BTU
Right Rear Type
Simmer
Dimensions and Weight
Width
30"
Height
3 3/8"
Gross Weight
58 Lbs.
Depth
21"
Cutout Width
28 7/8"
Cutout Depth
19 1/2"
Style and Extras
Power Boost
No
Hot Surface Indicator Light
No
Heating Element On Indicator Light
No
Downdraft Vent
No
Digital Display
No
Control Type
Knobs
Appearance
Trim Color
Stainless Steel
Surface Color
Stainless Steel
Style
Sealed Burner
Fuel Type
Gas
Cooktop
Cooktop
Continuous Grates
Yes
Color
Stainless Steel
Electrical Requirements
Volts
120
Amps
15
Configuration and Overview
Surface Material
Stainless Steel
Size
30"
Number of Burners
5
Installs Over Built-In Oven
Yes
Fuel Type
Gas
Cooktop Type
Standard
Burner or Element Style
Sealed Gas
Function
Downdraft Venting
No
Control Type
Knobs
Burners
5
Hot Surface Indicator Light
No
Sabbath Mode
No
Induction
No
Dimensions
Cutout Width
28 7/8"
Cutout Depth
19 1/2"
Actual Width
30"
Actual Height
3 3/8"
Actual Depth
21"
Burner Output
Griddle
No
Grill
No
Set 4 QTY
1
Set 4 Output
5000
Set 3 QTY
2
Set 3 Output
9100
Set 2 QTY
1
Set 2 Output
10000
Set 1 QTY
1
Set 1 Output
17000
General
Manufacturer
KitchenAid
