About the XO XOIL3019SC
- Cabinet Insert and Liner with 3-Speed 395/600 CFM Blower
- Code Compliance Control
- LED Lights
- Dishwasher Safe Stainless Baffle Filters
- Convertible Venting
- Optional ADA Compliant Remote: 30" Width (395/600 CFM)
Brand:
CFM:
600 CFM
Venting Type:
Convertible
Style:
Standard Hood
Width:
28 3/4"
Height:
12"
Depth:
19 1/4"
The XOIL series are designed as all-in-one blower/liner combination units for easy installation into custom hoods. Each XOIL model is designed and crafted in Italy to incorporate a multi-speed blower, controls, filtration, LED Lamps, and backflow damper. The all-in-one insert blower + liner is everything you need in one easy-to-install package.
About XO
From beginning to end XO will deliver more. They will be here to help specify and design the right ventilation for your home. They are ventilation experts. All XO quality products are backed by a comprehensive 2-year In-Home Warranty. Problems happen, they always do. Don't worry, XO will be there to help resolve the issue. Your total satisfaction is their main concern. XO is committed to its vision of becoming the most innovative, customer-oriented appliance company in the world.
Key Features
All-in-One Design
- All-in-one blower / liner combination design allows for easy installation into custom hoods.
3 Speed 395/600 CFM Motor
- Electronic 3 Speed Control + Power Boost provides up to 600 CFM ventilation
Code Compliance Control
- The hood can be configured for 395 CFM or 600 CFM during installation.
LED Lights
- High Efficiency 3000k LED Lights to illuminate your cooking surface.
Dishwasher Safe Stainless Steel Pro Baffle Filters
- They can be easily be removed for dishwasher-safe cleaning.
Made in Italy!
- These XO hoods are designed and crafted in Italy by ventilation experts.
- This heritage enables XO hoods to possess more style and higher quality than other brands.
Additional Features
- 3 Speed Electronic Illuminated Controls
- Convertible Venting
- Optional ADA Compliant Remote
- 5 Minute Delay Function
- High-Velocity Blower
- Incomparable Handcrafted Italian Finish
- UL Listed
XOIL3019SC Specification Sheet
Specifications
Smart
WiFi
No
Bluetooth
No
Features
Dishwasher Safe
Yes
Delay Off
5-Minute
Controls
Code Compliance Electronic Controls
Color
Stainless Steel
Air Circulation
600 CFM
Duct Size
6" Round Vertical Duct
Electrical Requirement
AC 115V - 60Hz (4 Amp)
Sones
1.0 - 6.5
Recirculation
Recirculation Capable
Recirculating Kit
Optional
Lighting
Twin LED Lights
Light Dimmer
3 Levels
LED Lights
2
Filters
Stainless Steel PRO Baffle filters
Dimensions
Width
28 3/8"
Size
30"
Mounting Height
27" - 32" Above Cooking Surface
Height
12"
Depth
19 1/4"
Cut Out
28 1/2" x 19 7/16"
Capacity
Sones
6.4
Permanent Air Flow Reduction
Yes
Noise Level
6.4 Sones
CFM
600 CFM
Duct Size
6 Inch
Dimensions
Width
28 3/4 Inch
Height
12 Inch
Depth
19 1/4 Inch
Technical Details
Voltage
120 Volts
CEE Rating
Not Available
Approved for Outdoor Use
No
Amps
15
Energy Star Rated
No
Appearance
Venting Type
Convertible
Type
Cabinet Insert
Style
Standard Hood
Mounting Type
Under Cabinet
Color
Stainless Steel
Blower Type
Internal
Blower Included
Yes
Glass Canopy
No
Fingerprint Resistant
No
GTIN
UPC
814830012818
JAN
814830012818
EAN
0814830012818
Features
Number of Fan Speeds
4
Delay Shut-Off
Yes
Lights
LED
Lighting Levels
3
Filter Type
Baffle
Dishwasher Safe Filters
Yes
Specifications:
Product Information
Brand
XO
Model
XOIL3019SC
General
Manufacturer
XO
