About the Zephyr ZAZM90DS
- Anzio Island Mount Range Hood with 5-Speed 600 CFM Blower
- ICON Touch™ Controls
- Airflow Control Technology™
- LumiLight LED Lighting
- Auto Delay Off
- Aluminum Mesh Filters
- Recirculating Option
- Quick Lock Installation
- ADA Compliant: 36" Width
Brand:
CFM:
600 CFM
Venting Type:
Convertible
Style:
Chimney Style
Width:
35 7/16"
Height:
31 1/2"
Depth:
25 9/16"
With its low-profile, bell-shaped design, Anzio adds style to any kitchen project. Its 600-CFM blower, ICON Touch® controls, and new LumiLight LED lighting move it ahead of the competition. Add the Quick-Lock Installation System with magnetic duct covers, and Anzio stands alone in terms of performance, design and value. Now available with an optional ADA-compliant remote control.
About Zephyr
Since the launch of its first hoods in 1997, Zephyr has remained true to its vision of delivering the unexpected-by deliberately seeking to change the marketplace. Zephyr was the first to recognize the unmet demand for more powerful, professional-grade hoods in the home. And they answered with the Power series, high-CFM performers that put air quality concerns to rest with quiet efficiency and raised the bar with self-cleaning, filter-free technologies never before seen.
Key Features
5-Speed 600 CFM Blower
- Powerful 5-Speed internal blower with speeds of 200CFM (1 Sones) to 600 CFM(6 Sones)
ICON Touch™ Controls
- Front touch controls give full access to all fan settings and lighting settings
Airflow Control Technology™
- ACT is a feature built into all Zephyr hoods with DCBL Suppression System technology allowing you to limit the maximum blower CFM to meet local code requirements
LumiLight LED Lighting
- Dual-level LED lighting illuminates the surface for more visibility
Auto Delay Off
- Allows you to set your hood to continue venting for 5 or 10 minutes after cooking is complete and then automatically powers your hood off
Quick Lock Installation
- Enhanced Quick-Lock Installation System with magnetic duct covers
Warranty
- 3-years parts, 1-year labor
ADA Compliant
- ADA Compliant with optional Remote
Additional Features
- Recirculating Option
- Aluminum Mesh Filters
Specifications
GTIN
UPC
646328010729
Smart
WiFi
No
Bluetooth
No
Dimensions
Height
31 1/2 Inch
Depth
25 9/16 Inch
Width
35 7/16 Inch
Appearance
Blower Type
Internal
Blower Included
Yes
Venting Type
Convertible
Mounting Type
Island Mount
Glass Canopy
No
Fingerprint Resistant
Yes
Color
Stainless Steel
Type
Hood
Style
Chimney Style
Capacity
CFM
600 CFM
Permanent Air Flow Reduction
Yes
Noise Level
6 Sones
Duct Size
6 Inch
Sones
6
Technical Details
Voltage
120 Volts
Amps
5
ADA Compliant
Yes
Features
Delay Shut-Off
Yes
Lights
LED
Lighting Levels
2
Filter Type
Mesh
Number of Fan Speeds
5
Product Information
Model
ZAZM90DS
Brand
Zephyr
Features
Dual-Level Lighting
Yes
Lighting
LumiLight LED, 6W x4
Auto Delay-Off
Yes
Speed Levels
5
Controls
ICON Touch®
ACT Technology
Yes
Color
Stainless Steel
Filters
Aluminum Mesh x2
Recirculating Option
Yes
Quick-Lock Installation
Yes
Extension Duct Cover Option
Yes, Up to 12' Ceiling
Magnetic Duct Covers
Yes
Blower Performance
ACT 290 CFM (Min. - Max.)
200 - 290
ACT 390 CFM (Min. - Max.)
200 - 390
Sones (Min. - Max.)
1 - 6
Blower CFM (Min. - Max.)
200 - 600
Blower Type
Internal
Warranty
Labor
1 Year
Parts
3 Years
Dimensions
Height
31 1/2"
Depth
25 9/16"
Width
35 7/16"
Mounting Height Range
26" - 34"
Electrical Specifications
AC Power
120V, 60Hz at Max. 4A
Duct Specifications
Vertical Internal Blower
6" Round
General
Series
Core Collection
Manufacturer
Zephyr
