About the Zephyr ZNAM90DS
- Napoli Island Mount Smart Range Hood with 6 Speed 700 CFM Blower
- Proximity Controls
- LED Light
- Baffle Filters
- ACT™ Technology
- PowerWave™
- Zephyr Connect
- Wi-Fi
- UL Listed
- ADA Compliant (with Remote or App): 36 Inch Width
Brand:
CFM:
700 CFM
Venting Type:
Convertible
Style:
Chimney Style
Width:
36"
Height:
50"
Depth:
25 9/16"
Robust, powerful, and sophisticated with upward-angled walls, Napoli makes a striking impression in any kitchen. Enhanced with a 700-CFM PowerWave™ blower, Zephyr Connect Technology, Proximity Touch Controls, and Tri-Level LumiLight LED Lighting, Napoli is a technological feat that stands above the rest. Including an enhanced Quick-Lock Installation System with magnetic duct covers, Napoli is as easy to install as it is to enjoy. Available with an optional wireless remote control. Control your range hood from anywhere using your mobile device with the Zephyr Connect App. Get real-time diagnostics and product information, and connect to smart devices such as Amazon Alexa or Google Home smart speakers. Download on mobile from the Apple App Store and Google Play today.
About Zephyr
Since the launch of their first hoods in 1997, Zephyr has remained true to its vision of delivering the unexpected by deliberately seeking to change the marketplace. Zephyr was the first to recognize the unmet demand for more powerful, professional-grade hoods in the home. And they answered with the Power series, high-CFM performers that put air quality concerns to rest with quiet efficiency and raised the bar with self-cleaning, filter-free technologies never before seen.
Key Features
6 Speed 700 CFM Blower
- A powerful blower that is efficient and quiet.
Tri-Level LumiLight LED Light
- The LED light offers the perfect mood option for your kitchen.
Baffle Filters
- Helps trap grease and remove smoke.
Airflow Control Technology™ (ACT™)
- ACT™ is an exclusive feature built into specific Zephyr hoods which can limit the maximum blower CFM to meet local code requirements.
PowerWave™ 3-Phase Blower Technology
- Delivers best-in-class performance with unparalleled quiet operation.
- It provides more power while minimizing noise and improving efficiency.
Zephyr Connect App
- Allows you to control your range hood from anywhere using your mobile device.
- It includes real-time diagnostics and provides important product information.
Wi-Fi Connect
- Control your hood with Amazon Alexa and Google Home.
Additional Features
- Proximity Touch Controls
- CleanAir Function
- Quick-Lock Installation System
Claims and Certifications
- UL Listed
- ADA Compliant (with Remote or App)
Specifications
Smart
WiFi
Yes
Smart Accessory Required
No
Dash Replenishment
No
Alexa
Yes
Remote Monitoring
Yes
Remote Diagnostics
Yes
Remote Control
Yes
Google Home
Yes
Features
Alexa & Google Home Compatible
Yes
ADA Compliant
Yes, with Zephyr Connect or Remote
ACT™ Technology
590, 390, 290
Auto Delay-Off
Yes
CleanAir Function
Yes
Zephyr Connect App Compatible
Yes
Tri-Level Lighting
Yes
Speed Levels
6
Recirculating Option
Yes
Quick-Lock Installation
Yes
Magnetic Duct Covers
Yes
Lighting
LumiLight LED, 6W x4
Filters
Baffle x2
Extension Duct Cover Option
Yes, Up to 12' Ceiling
Controls
Proximity Touch
Warranty
Parts
3 Years
Labor
1 Year
Blower Performance
Sones (Min. - Max.)
0.8 - 6
Blower CFM (Min. - Max.)
200 - 700
ACT 590 CFM (Min. - Max.)
200 - 590
ACT 390 CFM (Min. - Max.)
200 - 390
ACT 290 CFM (Min. - Max.)
200 - 290
Dimensions
Width
36"
Mounting Height Range
24" - 34"
Min. Recirc.
36 1/2"
Min. Ducted
32"
Max. Height
50"
Depth
25 9/16"
Duct Specifications
Vertical Internal Blower
8" Round
Horizontal Internal Blower
NA
Dimensions
Width
36 Inch
Depth
25 9/16 Inch
Height
50 Inch
Technical Details
Voltage
120 Volts
CEE Rating
Not Available
ADA Compliant
Yes
Energy Star Rated
No
Appearance
Venting Type
Convertible
Type
Hood
Style
Chimney Style
Color
Stainless Steel
Blower Type
Internal
Blower Included
Yes
Mounting Type
Island Mount
Glass Canopy
No
Fingerprint Resistant
No
GTIN
UPC
646328008467
Electrical Specifications
AC Power
120V, 60Hz at Max. 5A
Capacity
Sones
6
CFM
700 CFM
Duct Size
8 Inch
Permanent Air Flow Reduction
Yes
Noise Level
6 Sones
Features
Dishwasher Safe Filters
Yes
Delay Shut-Off
Yes
Number of Fan Speeds
6
Lights
LED
Lighting Levels
3
Filter Type
Baffle
Specifications:
Series
Core Collection
Product Information
Brand
Zephyr
MPN
ZNA-M90DS
Model
ZNAM90DS
General
Manufacturer
Zephyr
